Motor Controller 7.5 A CAN DTM

SKU: 1.117.9

166,23 € inc. VAT

plus Shipping Costs

All prices in order options

See order options
Description

The Motor Controller 7.5 A CAN DTM is used for the control of DC motors. Due to the free programmability and the compact design, you can implement a wide range of applications in the smallest of spaces. In combination with the DEUTSCH DTM connector, it offers you robust quality and is ideally suited for extreme environmental conditions.

Additional information
Inputs & Outputs
Number of pins: 8
Inputs (total): 1
Inputs (analog): 1
In-/Outputs (total): 2
Outputs (total): 1
Fullbridge: 1
Switching current: 7.5 A
Interfaces
CAN interface(s): 1
Programming
Programming software: MRS Developers Studio
Mechanical properties
IP rating: IP6K8
Housing material: PA66GF30
General information
Temperature range: -40 °C to +85 °C
Operating voltage: 6-32 V
Current consumption: 23 mA
Quiescent current (12V): 700 µA
Quiescent current (24V): 1280 µA
Processor architecture: 8 bit
Product safety
Downloads
Data sheet Motor Controller 7.5 A CAN DTM (German)
Download
Data sheet Motor Controller 7.5 A CAN DTM (English)
Download
DEUTSCH DTM product flyer
Download
Operating instruction Motor Controllers
Download
EU Declaration of Conformity
Download
Order options
Order No.
Name
Order No.
1.117.900.0000
Name
Wake Up Possibility KL15, CAN HS
166,23 € inc. VAT
