Frequency Monitor 12 V

SKU: 1.026.1x

53,91 € inc. VAT

plus Shipping Costs

Clear

All prices in order options

See order options
Description

The frequency monitor measures the input signal frequency applied to terminal 15 and energizes/deenergizes the output when the signal frequency exceeds/drops below the defined threshold frequency. The threshold frequency can be selected from the 10 – 1.000 Hz frequency range. In addition, combinations including custom delay times are possible. Please refer to the chapter housing and base plates for additional housing options.

Additional information
Inputs & Outputs
Number of pins: 5
Inputs (total): 1
Inputs (digital): 1
In-/Outputs (total): 2
Outputs (total): 1
Relay outputs: 1
Switching current: NO 15 A / NC 5 A
Programming
Programming software: MRS Realizer
Mechanical properties
IP rating: IP53
Housing material: PA66GF30
Dimensions: 30 × 30 × 40 mm
Switching cycles: 100000
General information
Temperature range: -40 to +85°C
Operating voltage: 10-16 V
Current consumption: 0.3 mA
Product safety

Downloads
EU Declaration of Conformity
Download
Order options
Order No.
Name
Order No.
1.026.111.00
Name
Relay A, Type A, Connection S1
53,91 € inc. VAT
Order No.
1.026.111.002
Name
Relay A, Type A, Connection S1, 2 Hz
53,91 € inc. VAT
Order No.
1.026.111.027E
Name
Type A, Connection S1, 12V 27Hz
53,91 € inc. VAT
Order No.
1.026.111.125
Name
Type A, Connection S1, 12V 125Hz
53,91 € inc. VAT
Order No.
1.026.112.00
Name
Relay B, Type B, Connection S2
53,91 € inc. VAT
